◇1/3inch Sony CCD高清影像传感器 ◇分辩率：1280*720/720*480/640*480fps,每秒25fps ◇功能：录像/拍照/视频回放 ◇拍摄角度：120度 ◇数码变焦：8倍 ◇视频输出：TV-OUT ◇供电：5V1A ◇分段录像，可自行选择自录时间：1分钟/5分钟/10分钟 ◇接口：USB2.0 ◇时间日期水印功能，录像时可以实时显示时间和日期 ◇拍摄光照度：0LUX ◇SD卡，最高支持32GB ◇支持多国语言(可选）：简单中文/繁体中文/英语/日语/俄语/法语/西班牙语/葡萄牙语 ◇-10℃-70℃ ◇可选配件：3.5inch 显示屏 后视摄像头 Product Description 1/3" SONY CCD 520TVL Mobile Car DVR Features: *1/3" SONY CCD + SONY SS-11 X DSP Color Camera built-in *Exclusive Technology-CCD digital signal directly into DVR compression chipset, digital high definition recorded files comes to reality. *D1 resolution recorded in size of 720*480 frame rate 25fps *Bonus audio recording high sensitivity noise free detachable microphone *Plug and play SD card with player in free from software installations *Fool proof power cables of safety *Auto run recording after SD card plug-in and power supplied Pick-up Device 1/3” Sony CCD + Sony-11 X DSP Picture Element 768*494 pixel Lens Mount 120 degrees Live View 30fps/520TVL Video Output 1.0Vp-p / 75Ohms. RCA Compression chip MJPGE Video streams from CCD in synchronization technique Recorded Format D1: 720*480, VGA:640*480，HD:1280*720 ，25FS Audio Input Detachable microphone Recorded Data Time & Date / Video/ Audio Storage SD Card 32GB player software embedded Indicators Green: Power/ Red: Recording/ Blue Mount Wind Shield Suction Cup mount Upgrade SD Card software upgrade Power range 12V DC-24V DC Operating Temperature -15 ~ +70 temperature (Vehicle inside)

高清CMOS芯片分辨率420线/480线可选防水防震防雾免打孔安装方便视角170° 制式NTSC/PAL 可调镜像/原像尺寸18.5mm*21mm 可显示倒车参考线 视频制式 NTSC、PAL 图像传感器 1/4" / 1/3" CMOS 有效像素 648（H）*488（V） 水平解像度 420/480 TV Lines 可选 是低照度 0.5Lux 同步系统 内同步 信噪比 ≥48dB(AGC OFF) 电子快门 1/60s-20us 白平衡 AUTO 伽玛特性 AUTO 操作温度 -30℃-65℃ RH95% Max 储存温度 -40℃-80℃ RH95% Max 视频输出 1.0Vp-p,75Ω 电源功耗 DC12V

功能特点： *为倒车安全，车载娱乐匠心设计 *兼容所有汽车后视摄像头 *高清晰，高亮度LCD面板 做工精细！高贵典雅！ 参数： 种类：TFT-LCD(4:3)数字屏 显示尺寸：3.5 寸 分辨率：320*240（全新原装屏，市场很多用旧屏做的） 显示格式：4:3 功率≤3W 电源：DC12V/DC5V 视频：一路倒车后视输入,一路DVD/行车记录仪等 视频输入制式：PAL/NTSC自动识别 倒车功能：连接摄像头后可实现自动切换后视及自动唤醒功能 适用范围：工控，税控，仪器仪表，电脑显示器，安防监控，POS终端，车载显示器，商用显示终端等。 液晶显示器小巧方便,支架可以上下左右移动（360度旋转）,根本客户所需要的视角而调整.可做成车载显示器.监视器等多种用途! 屏幕大小：71*53mm 外壳尺寸：108*69*19mm 产品卖点：特有吸盘支架，轻松安装，方便固定，可全方位调整角度 Specification: 3.5inch TFT-LCD Color Monitor 2-channelvideo input:V1/V2(Auto switching) Video Frequency: PAL/NTSC Connect VCD/DVD/GPS/ Car Black Box/Car reserving camera etc It can connect with VCD and DVD signal Placement: Dashboard, windshield or overhead location Screen Size: 3.5 inch(4: 3) Contrast Ratio: 350:1 Resolution: 640(H) x RGB x 480 (V) Power Supply: DC 12V Visible Area: 72 x 53.56 Power Consumption: 0.53W Input voltage: 5V/12V Display shut on no signal. Working temperature: 0-40 degree Dimensions:108mm (L) x 69mm(W) x 19mm(H) Note: please Connect the Rearview camera's power cable with Reversing lamp, and connect camera's video cable with LCD's yellow cable(Video V1),then the LCD will show Camera's video when you are Reversing, and stop playing movie. Display black screen on no signal. Package includes: 1 * 3.5" LCD Car Rearview Mirror Monitor 1 * Power cable (1.35M)

高清CMOS芯片分辨率420线/480线可选防水防震防雾免打孔安装方便视角170° 制式NTSC/PAL 可调镜像/原像尺寸18.5mm*21mm 可显示倒车参考线 视频制式 NTSC、PAL 图像传感器 1/4" / 1/3" CMOS 有效像素 648（H）*488（V） 水平解像度 420/480 TV Lines 可选 是低照度 0.5Lux 同步系统 内同步 信噪比 ≥48dB(AGC OFF) 电子快门 1/60s-20us 白平衡 AUTO 伽玛特性 AUTO 操作温度 -30℃-65℃ RH95% Max 储存温度 -40℃-80℃ RH95% Max 视频输出 1.0Vp-p,75Ω 电源功耗 DC12V

功能特点： *为倒车安全，车载娱乐匠心设计 *兼容所有汽车后视摄像头 *高清晰，高亮度LCD面板 做工精细！高贵典雅！ 参数： 种类：TFT-LCD(4:3)数字屏 显示尺寸：3.5 寸 分辨率：320*240（全新原装屏，市场很多用旧屏做的） 显示格式：4:3 功率≤3W 电源：DC12V/DC5V 视频：一路倒车后视输入,一路DVD/行车记录仪等 视频输入制式：PAL/NTSC自动识别 倒车功能：连接摄像头后可实现自动切换后视及自动唤醒功能 适用范围：工控，税控，仪器仪表，电脑显示器，安防监控，POS终端，车载显示器，商用显示终端等。 液晶显示器小巧方便,支架可以上下左右移动（360度旋转）,根本客户所需要的视角而调整.可做成车载显示器.监视器等多种用途! 屏幕大小：71*53mm 外壳尺寸：108*69*19mm 产品卖点：特有吸盘支架，轻松安装，方便固定，可全方位调整角度 Specification: 3.5inch TFT-LCD Color Monitor 2-channelvideo input:V1/V2(Auto switching) Video Frequency: PAL/NTSC Connect VCD/DVD/GPS/ Car Black Box/Car reserving camera etc It can connect with VCD and DVD signal Placement: Dashboard, windshield or overhead location Screen Size: 3.5 inch(4: 3) Contrast Ratio: 350:1 Resolution: 640(H) x RGB x 480 (V) Power Supply: DC 12V Visible Area: 72 x 53.56 Power Consumption: 0.53W Input voltage: 5V/12V Display shut on no signal. Working temperature: 0-40 degree Dimensions:108mm (L) x 69mm(W) x 19mm(H) Note: please Connect the Rearview camera's power cable with Reversing lamp, and connect camera's video cable with LCD's yellow cable(Video V1),then the LCD will show Camera's video when you are Reversing, and stop playing movie. Display black screen on no signal. Package includes: 1 * 3.5" LCD Car Rearview Mirror Monitor 1 * Power cable (1.35M)

产品强大卖点: (一) 超强8倍数位变焦：不需要再担心拍摄不到违章者的车牌号码，只需要手指轻轻一按，马上可以拍摄到清晰的画面 (二) 500万高清拍照：遇到事故不用愁，录像，拍照样样都行，数码相机可以在家歇息了！ (三) 本机采用知名台湾AUO品牌2.8寸高清数字液晶显示屏，画面看得更广更清晰 (四) 内置120度超广角镜头 (五) 超强低照度夜视模式，夜间仅需打开汽车大灯，即可拍摄到夜间精美的清晰画面！红外灯-OUT了 (六) 横向设计，安装更隐蔽：考虑到驾驶安全，特采用横向设计，可将产品安装在汽车后视镜后面，避免影响驾驶视线！产品规格： ◆HD 720P HDMI高画质 行车记录器 ◆500，000万高清CMOS影像传感器 ◆2.8寸高清数字液晶显示屏 ◆内置120度广角高清镜头 ◆影音储存档案：AVI(H.264) ◆录像设定时间：1/5/10分钟 ◆循环录像功能：可自行设置是否为开/关 ◆输出接口：HDMI、AV、USB输出 ◆影像分辨率：1280x720/848x480/640x480 ◆拍照：500万像素 ◆拍照储存档案：JPEG檔 ◆拍照分辨率：4032*3024/1280x720/2304x1296 /640*480 ◆数码变焦：8倍 ◆语言：英文，简/繁中文，法语，德语，俄语，日语，葡萄牙语，西班牙语 ◆内存：支持64GB SDHC卡 可超长时间录像 ◆供电：使用车用电源供电 ◆日期时间显示：显示或不显示 ◆支援音频:录音功能“有” ◆夜间录像效果极佳可轻松捕捉行车过程中的美丽夜景 ◆视讯输出：HDMI 、AV-OUT ◆通电自动录像：有 ◆自动覆盖功能：有 ◆移动侦测：有 ◆随机附件：专用支架、USB连接线、车充电源、AV连接线 ◆机身尺吋：88*65*23mm ◆重量：100g ◆工作温度：-10度C~70度C ◆是市面上无法提供的2倍最强夜间摄影 夜间真实录像，非一般的录像效果： 项目 规格屏幕尺寸 2.8寸高清数字显示屏感应芯片 500万高清CMOS影像传感器视频分辨率 1280*720/640*480/320*240 视频帧率 10/15/20/30 照片分辨率 4032*3024/3264*2448/2592*1944/2048*1536/1280*960/640*480 压缩格式 H.264 文檔格式 视频：AVI 录音：WAV 拍照：JPEG 视频保存时间 1分钟/5分钟/10分钟数码变焦 8倍数码变焦循环录像 可自行设置是否循环录像录制功能 音视频/录像/录音/运动侦测播放功能 视频/照片/MP3 音频输入/出 麦克风/喇叭界面 TV输出孔 视频输出 USB界面 供电/读取数据支持多国语言 英文，简/繁中文，法语，德语，俄语，日语，葡萄牙语，西班牙语存储媒体 SD卡，最高支持64GB 电源 车载电源/内置电池机器尺寸 88*65*23MM 机器重量 100g 工作温度 -10℃-70℃ Product Description: Car black box or drive video recorder is a device installed in car windshield to record video, audio data related to vehicle impact or accidents. Imformation from device is stored in memory card and can be analyzed to help determine what the vehicles were doing before, during and after the crash or event. The turm generally refers to a simple, tamper-proof, read-write memory device, similar to the "black box" found on airplanes(as opposed to the tape recorders and video cameras common in police vehicles and many commercial trucks). Product Features 1.Ultra strong 8 multiple position focal variation: Does not need to worry again does not photograph the violating regulations car license number, as soon as only needs the finger to press gently, may photograph the clear picture 2.5000K HD photography: Comes across the accident not to need to worry, video recording, photograph every kind good, the digital camera rested in the home! 3.This aircraft uses the well-known Taiwan AUO brand 2.8 inch high clear digit liquid crystal display monitor, the picture looks widely is clearer 4.Built-in 140 degrees ultra wide-angle lens 5.Iow light intensity night vision pattern, only need turn on the automobile head lamp headlamp at night, then photographs at night fine clear video recording effect! Infra-red lamp - OUT 6.The crosswise design, the installment is more covert: The consideration driving security, uses the crosswise design specially, may install the product behind the automobile rear view mirror, avoids affecting the driving line of sight! Accessories: Mount, Car charger, User manual, AV cable, USB cable Item Specification Screen Size 2.8 inch display screen Sensor Chip Video Resolution 1280*720/ 640*480/ 320*240 Video Frame Rate 10/ 15/ 20/ 30 fps Picture Resolution 403 4032*3024/3264*2448/2592*1944/2048*1536/ 128 1280*960/640*480 Compressed Format H.264 Shooting Angle 140 Degrees File Format Video：AVI Record：WAV Photo：JPEG Video Saving Time 1/ 5/ 10 minutes Digital Zoom ×8 Loop Recording Set up by the user Recording Function AV/ Video/ Tape/ Motion detection Play Function Video/ Photo/ MP3 Audio Input / Output MIC、Speaker Interface TV-output Hole Video output HDMI HD video output USB Power supply/ data read Support Multinational Languages English,Simple/traditionalChinese,Franch,German,Russian,Japaness,Portugues,Spain Storage Medium SD card, up to 32GB Power Source Car charger/ built-in battery Product Size 88*65*23MM Product Weight 100g Operate Temperature -10℃-70℃ Product Description: Car black box or drive video recorder is a device installed in car windshield to record video, audio data related to vehicle impact or accidents. Imformation from device is stored in memory card and can be analyzed to help determine what the vehicles were doing before, during and after the crash or event. The turm generally refers to a simple, tamper-proof, read-write memory device, similar to the "black box" found on airplanes(as opposed to the tape recorders and video cameras common in police vehicles and many commercial trucks). Product Features 1.Ultra strong 8 multiple position focal variation: Does not need to worry again does not photograph the violating regulations car license number, as soon as only needs the finger to press gently, may photograph the clear picture 2.5000K HD photography: Comes across the accident not to need to worry, video recording, photograph every kind good, the digital camera rested in the home! 3.This aircraft uses the well-known Taiwan AUO brand 2.8 inch high clear digit liquid crystal display monitor, the picture looks widely is clearer 4.Built-in 140 degrees ultra wide-angle lens 5.Iow light intensity night vision pattern, only need turn on the automobile head lamp headlamp at night, then photographs at night fine clear video recording effect! Infra-red lamp - OUT 6.The crosswise design, the installment is more covert: The consideration driving security, uses the crosswise design specially, may install the product behind the automobile rear view mirror, avoids affecting the driving line of sight! Accessories: Mount, Car charger, User manual, AV cable, USB cable Item Specification Screen Size 2.8 inch display screen Sensor Chip Video Resolution 1280*720/ 640*480/ 320*240 Video Frame Rate 10/ 15/ 20/ 30 fps Picture Resolution 403 4032*3024/3264*2448/2592*1944/2048*1536/ 128 1280*960/640*480 Compressed Format H.264 Shooting Angle 140 Degrees File Format Video：AVI Record：WAV Photo：JPEG Video Saving Time 1/ 5/ 10 minutes Digital Zoom ×8 Loop Recording Set up by the user Recording Function AV/ Video/ Tape/ Motion detection Play Function Video/ Photo/ MP3 Audio Input / Output MIC、Speaker Interface TV-output Hole Video output HDMI HD video output USB Power supply/ data read Support Multinational Languages English,Simple/traditionalChinese,Franch,German,Russian,Japaness,Portugues,Spain Storage Medium SD card, up to 32GB Power Source Car charger/ built-in battery Product Size 88*65*23MM Product Weight 100g Operate Temperature -10℃-70℃

◇1/3inch Sony CCD高清影像传感器 ◇分辩率：1280*720/720*480/640*480fps,每秒25fps ◇功能：录像/拍照/视频回放 ◇拍摄角度：120度 ◇数码变焦：8倍 ◇视频输出：TV-OUT ◇供电：5V1A ◇分段录像，可自行选择自录时间：1分钟/5分钟/10分钟 ◇接口：USB2.0 ◇时间日期水印功能，录像时可以实时显示时间和日期 ◇拍摄光照度：0LUX ◇SD卡，最高支持32GB ◇支持多国语言(可选）：简单中文/繁体中文/英语/日语/俄语/法语/西班牙语/葡萄牙语 ◇-10℃-70℃ ◇可选配件：3.5inch 显示屏 后视摄像头 Product Description 1/3" SONY CCD 520TVL Mobile Car DVR Features: *1/3" SONY CCD + SONY SS-11 X DSP Color Camera built-in *Exclusive Technology-CCD digital signal directly into DVR compression chipset, digital high definition recorded files comes to reality. *D1 resolution recorded in size of 720*480 frame rate 25fps *Bonus audio recording high sensitivity noise free detachable microphone *Plug and play SD card with player in free from software installations *Fool proof power cables of safety *Auto run recording after SD card plug-in and power supplied Pick-up Device 1/3” Sony CCD + Sony-11 X DSP Picture Element 768*494 pixel Lens Mount 120 degrees Live View 30fps/520TVL Video Output 1.0Vp-p / 75Ohms. RCA Compression chip MJPGE Video streams from CCD in synchronization technique Recorded Format D1: 720*480, VGA:640*480，HD:1280*720 ，25FS Audio Input Detachable microphone Recorded Data Time & Date / Video/ Audio Storage SD Card 32GB player software embedded Indicators Green: Power/ Red: Recording/ Blue Mount Wind Shield Suction Cup mount Upgrade SD Card software upgrade Power range 12V DC-24V DC Operating Temperature -15 ~ +70 temperature (Vehicle inside)

Product Description: Car black box or drive video recorder is a device installed in car windshield to record video, audio data related to vehicle impact or accidents. Imformation from device is stored in memory card and can be analyzed to help determine what the vehicles were doing before, during and after the crash or event. The turm generally refers to a simple, tamper-proof, read-write memory device, similar to the "black box" found on airplanes(as opposed to the tape recorders and video cameras common in police vehicles and many commercial trucks). Product Features 1.Ultra strong 8 multiple position focal variation: Does not need to worry again does not photograph the violating regulations car license number, as soon as only needs the finger to press gently, may photograph the clear picture 2.5000K HD photography: Comes across the accident not to need to worry, video recording, photograph every kind good, the digital camera rested in the home! 3.This aircraft uses the well-known Taiwan AUO brand 2.8 inch high clear digit liquid crystal display monitor, the picture looks widely is clearer 4.Built-in 140 degrees ultra wide-angle lens 5.Iow light intensity night vision pattern, only need turn on the automobile head lamp headlamp at night, then photographs at night fine clear video recording effect! Infra-red lamp - OUT 6.The crosswise design, the installment is more covert: The consideration driving security, uses the crosswise design specially, may install the product behind the automobile rear view mirror, avoids affecting the driving line of sight! Accessories: Mount, Car charger, User manual, AV cable, USB cable Item Specification Screen Size 2.8 inch display screen Sensor Chip Video Resolution 1280*720/ 640*480/ 320*240 Video Frame Rate 10/ 15/ 20/ 30 fps Picture Resolution 403 4032*3024/3264*2448/2592*1944/2048*1536/ 128 1280*960/640*480 Compressed Format H.264 Shooting Angle 140 Degrees File Format Video：AVI Record：WAV Photo：JPEG Video Saving Time 1/ 5/ 10 minutes Digital Zoom ×8 Loop Recording Set up by the user Recording Function AV/ Video/ Tape/ Motion detection Play Function Video/ Photo/ MP3 Audio Input / Output MIC、Speaker Interface TV-output Hole Video output HDMI HD video output USB Power supply/ data read Support Multinational Languages English,Simple/traditionalChinese,Franch,German,Russian,Japaness,Portugues,Spain Storage Medium SD card, up to 32GB Power Source Car charger/ built-in battery Product Size 88*65*23MM Product Weight 100g Operate Temperature -10℃-70℃ 产品强大卖点: (一) 超强8倍数位变焦：不需要再担心拍摄不到违章者的车牌号码，只需要手指轻轻一按，马上可以拍摄到清晰的画面 (二) 500万高清拍照：遇到事故不用愁，录像，拍照样样都行，数码相机可以在家歇息了！ (三) 本机采用知名台湾AUO品牌2.8寸高清数字液晶显示屏，画面看得更广更清晰 (四) 内置120度超广角镜头 (五) 超强低照度夜视模式，夜间仅需打开汽车大灯，即可拍摄到夜间精美的清晰画面！红外灯-OUT了 (六) 横向设计，安装更隐蔽：考虑到驾驶安全，特采用横向设计，可将产品安装在汽车后视镜后面，避免影响驾驶视线！产品规格： ◆HD 720P HDMI高画质 行车记录器 ◆500，000万高清CMOS影像传感器 ◆2.8寸高清数字液晶显示屏 ◆内置120度广角高清镜头 ◆影音储存档案：AVI(H.264) ◆录像设定时间：1/5/10分钟 ◆循环录像功能：可自行设置是否为开/关 ◆输出接口：HDMI、AV、USB输出 ◆影像分辨率：1280x720/848x480/640x480 ◆拍照：500万像素 ◆拍照储存档案：JPEG檔 ◆拍照分辨率：4032*3024/1280x720/2304x1296 /640*480 ◆数码变焦：8倍 ◆语言：英文，简/繁中文，法语，德语，俄语，日语，葡萄牙语，西班牙语 ◆内存：支持64GB SDHC卡 可超长时间录像 ◆供电：使用车用电源供电 ◆日期时间显示：显示或不显示 ◆支援音频:录音功能“有” ◆夜间录像效果极佳可轻松捕捉行车过程中的美丽夜景 ◆视讯输出：HDMI 、AV-OUT ◆通电自动录像：有 ◆自动覆盖功能：有 ◆移动侦测：有 ◆随机附件：专用支架、USB连接线、车充电源、AV连接线 ◆机身尺吋：88*65*23mm ◆重量：100g ◆工作温度：-10度C~70度C ◆是市面上无法提供的2倍最强夜间摄影 夜间真实录像，非一般的录像效果： 项目 规格屏幕尺寸 2.8寸高清数字显示屏感应芯片 500万高清CMOS影像传感器视频分辨率 1280*720/640*480/320*240 视频帧率 10/15/20/30 照片分辨率 4032*3024/3264*2448/2592*1944/2048*1536/1280*960/640*480 压缩格式 H.264 文檔格式 视频：AVI 录音：WAV 拍照：JPEG 视频保存时间 1分钟/5分钟/10分钟数码变焦 8倍数码变焦循环录像 可自行设置是否循环录像录制功能 音视频/录像/录音/运动侦测播放功能 视频/照片/MP3 音频输入/出 麦克风/喇叭界面 TV输出孔 视频输出 USB界面 供电/读取数据支持多国语言 英文，简/繁中文，法语，德语，俄语，日语，葡萄牙语，西班牙语存储媒体 SD卡，最高支持64GB 电源 车载电源/内置电池机器尺寸 88*65*23MM 机器重量 100g 工作温度 -10℃-70℃

产品强大卖点: (一) 超强8倍数位变焦：不需要再担心拍摄不到违章者的车牌号码，只需要手指轻轻一按，马上可以拍摄到清晰的画面 (二) 500万高清拍照：遇到事故不用愁，录像，拍照样样都行，数码相机可以在家歇息了！ (三) 本机采用知名台湾AUO品牌2.8寸高清数字液晶显示屏，画面看得更广更清晰 (四) 内置120度超广角镜头 (五) 超强低照度夜视模式，夜间仅需打开汽车大灯，即可拍摄到夜间精美的清晰画面！红外灯-OUT了 (六) 横向设计，安装更隐蔽：考虑到驾驶安全，特采用横向设计，可将产品安装在汽车后视镜后面，避免影响驾驶视线！产品规格： ◆HD 720P HDMI高画质 行车记录器 ◆500，000万高清CMOS影像传感器 ◆2.8寸高清数字液晶显示屏 ◆内置120度广角高清镜头 ◆影音储存档案：AVI(H.264) ◆录像设定时间：1/5/10分钟 ◆循环录像功能：可自行设置是否为开/关 ◆输出接口：HDMI、AV、USB输出 ◆影像分辨率：1280x720/848x480/640x480 ◆拍照：500万像素 ◆拍照储存档案：JPEG檔 ◆拍照分辨率：4032*3024/1280x720/2304x1296 /640*480 ◆数码变焦：8倍 ◆语言：英文，简/繁中文，法语，德语，俄语，日语，葡萄牙语，西班牙语 ◆内存：支持64GB SDHC卡 可超长时间录像 ◆供电：使用车用电源供电 ◆日期时间显示：显示或不显示 ◆支援音频:录音功能“有” ◆夜间录像效果极佳可轻松捕捉行车过程中的美丽夜景 ◆视讯输出：HDMI 、AV-OUT ◆通电自动录像：有 ◆自动覆盖功能：有 ◆移动侦测：有 ◆随机附件：专用支架、USB连接线、车充电源、AV连接线 ◆机身尺吋：88*65*23mm ◆重量：100g ◆工作温度：-10度C~70度C ◆是市面上无法提供的2倍最强夜间摄影 夜间真实录像，非一般的录像效果： 项目 规格屏幕尺寸 2.8寸高清数字显示屏感应芯片 500万高清CMOS影像传感器视频分辨率 1280*720/640*480/320*240 视频帧率 10/15/20/30 照片分辨率 4032*3024/3264*2448/2592*1944/2048*1536/1280*960/640*480 压缩格式 H.264 文檔格式 视频：AVI 录音：WAV 拍照：JPEG 视频保存时间 1分钟/5分钟/10分钟数码变焦 8倍数码变焦循环录像 可自行设置是否循环录像录制功能 音视频/录像/录音/运动侦测播放功能 视频/照片/MP3 音频输入/出 麦克风/喇叭界面 TV输出孔 视频输出 USB界面 供电/读取数据支持多国语言 英文，简/繁中文，法语，德语，俄语，日语，葡萄牙语，西班牙语存储媒体 SD卡，最高支持64GB 电源 车载电源/内置电池机器尺寸 88*65*23MM 机器重量 100g 工作温度 -10℃-70℃ Product Description: Car black box or drive video recorder is a device installed in car windshield to record video, audio data related to vehicle impact or accidents. Imformation from device is stored in memory card and can be analyzed to help determine what the vehicles were doing before, during and after the crash or event. The turm generally refers to a simple, tamper-proof, read-write memory device, similar to the "black box" found on airplanes(as opposed to the tape recorders and video cameras common in police vehicles and many commercial trucks). Product Features 1.Ultra strong 8 multiple position focal variation: Does not need to worry again does not photograph the violating regulations car license number, as soon as only needs the finger to press gently, may photograph the clear picture 2.5000K HD photography: Comes across the accident not to need to worry, video recording, photograph every kind good, the digital camera rested in the home! 3.This aircraft uses the well-known Taiwan AUO brand 2.8 inch high clear digit liquid crystal display monitor, the picture looks widely is clearer 4.Built-in 140 degrees ultra wide-angle lens 5.Iow light intensity night vision pattern, only need turn on the automobile head lamp headlamp at night, then photographs at night fine clear video recording effect! Infra-red lamp - OUT 6.The crosswise design, the installment is more covert: The consideration driving security, uses the crosswise design specially, may install the product behind the automobile rear view mirror, avoids affecting the driving line of sight! Accessories: Mount, Car charger, User manual, AV cable, USB cable Item Specification Screen Size 2.8 inch display screen Sensor Chip Video Resolution 1280*720/ 640*480/ 320*240 Video Frame Rate 10/ 15/ 20/ 30 fps Picture Resolution 403 4032*3024/3264*2448/2592*1944/2048*1536/ 128 1280*960/640*480 Compressed Format H.264 Shooting Angle 140 Degrees File Format Video：AVI Record：WAV Photo：JPEG Video Saving Time 1/ 5/ 10 minutes Digital Zoom ×8 Loop Recording Set up by the user Recording Function AV/ Video/ Tape/ Motion detection Play Function Video/ Photo/ MP3 Audio Input / Output MIC、Speaker Interface TV-output Hole Video output HDMI HD video output USB Power supply/ data read Support Multinational Languages English,Simple/traditionalChinese,Franch,German,Russian,Japaness,Portugues,Spain Storage Medium SD card, up to 32GB Power Source Car charger/ built-in battery Product Size 88*65*23MM Product Weight 100g Operate Temperature -10℃-70℃ Product Description: Car black box or drive video recorder is a device installed in car windshield to record video, audio data related to vehicle impact or accidents. Imformation from device is stored in memory card and can be analyzed to help determine what the vehicles were doing before, during and after the crash or event. The turm generally refers to a simple, tamper-proof, read-write memory device, similar to the "black box" found on airplanes(as opposed to the tape recorders and video cameras common in police vehicles and many commercial trucks). Product Features 1.Ultra strong 8 multiple position focal variation: Does not need to worry again does not photograph the violating regulations car license number, as soon as only needs the finger to press gently, may photograph the clear picture 2.5000K HD photography: Comes across the accident not to need to worry, video recording, photograph every kind good, the digital camera rested in the home! 3.This aircraft uses the well-known Taiwan AUO brand 2.8 inch high clear digit liquid crystal display monitor, the picture looks widely is clearer 4.Built-in 140 degrees ultra wide-angle lens 5.Iow light intensity night vision pattern, only need turn on the automobile head lamp headlamp at night, then photographs at night fine clear video recording effect! Infra-red lamp - OUT 6.The crosswise design, the installment is more covert: The consideration driving security, uses the crosswise design specially, may install the product behind the automobile rear view mirror, avoids affecting the driving line of sight! Accessories: Mount, Car charger, User manual, AV cable, USB cable Item Specification Screen Size 2.8 inch display screen Sensor Chip Video Resolution 1280*720/ 640*480/ 320*240 Video Frame Rate 10/ 15/ 20/ 30 fps Picture Resolution 403 4032*3024/3264*2448/2592*1944/2048*1536/ 128 1280*960/640*480 Compressed Format H.264 Shooting Angle 140 Degrees File Format Video：AVI Record：WAV Photo：JPEG Video Saving Time 1/ 5/ 10 minutes Digital Zoom ×8 Loop Recording Set up by the user Recording Function AV/ Video/ Tape/ Motion detection Play Function Video/ Photo/ MP3 Audio Input / Output MIC、Speaker Interface TV-output Hole Video output HDMI HD video output USB Power supply/ data read Support Multinational Languages English,Simple/traditionalChinese,Franch,German,Russian,Japaness,Portugues,Spain Storage Medium SD card, up to 32GB Power Source Car charger/ built-in battery Product Size 88*65*23MM Product Weight 100g Operate Temperature -10℃-70℃
