产品简介 Mini PCIe DOM Specifications Capacities 1.5/3/6/12GB interface Mini PCIe (PCI Express1.1) Data Transfer Rate 60MB/sec. 35MB/sec. Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Vibration 20G(7~2000Hz) Shock 1500G/0.5ms DC Input Voltage 3.3V Power Consumption 300mA(max.) Operation Temp. 30x50.95x3.4mm (WxLxH) Mini DOM Specifications Capacities 2/4/8/16GB interface Mini PCIe (SATA II & USB 2.0) Data Transfer Rate 100MB/sec. (max.) 60MB/sec. (max.) Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Vibration 20G(7~2000Hz) Shock 1500G/0.5ms DC Input Voltage 3.3V Power Consumption 250mA(MAX.) Operation Temp. 30x50.95x3.4mm (WxLxH) USB interface Support Mini DOM-U Specifications Capacities 2/4/8/16GB interface Mini PCIe (USB 2.0) Data Transfer Rate 30MB/sec. (max.) 20MB/sec. (max.) Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Vibration 20G(7~2000Hz) Shock 1500G/0.5ms DC Input Voltage 3.3V Power Consumption 120mA(MAX.) Operation Temp. 30x50.95x3.4mm (WxLxH) USB interface Support Mini DOM DRPM-16GJ11C1D DRPM-08GJ11C1D DRPM-04GJ11C1D DRPM-02GJ11C1S   mSATA DRPS-16GJ11C1D DRPS-08GJ11C1D DRPS-04GJ11C1D DRPS-02GJ11C1S MiniDOM-U DRRU-16GI21AC2DS DRRU-08GI21AC2DS DRRU-04GI21AC2DS DRRU-02GI21AC2DS WT MiniDOM-U DRRU-16GI21AW2DS DRRU-08GI21AW2DS DRRU-04GI21AW2DS DRRU-02GI21AW2DS Mini PCIe DOM DRPP-16GM11C1D DRPP-08GM11C1D DRPP-04GM11C1D DRPP-02GM11C1D 北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com

产品简介 FiD 2.5” SATA 10000     技术规格           容量 8GB-----128GB           接口 Series ATAII                       尖峰速度 300Mbyte/sec           数据传输速率 读 : 160MB/sec (max.) 写 : 140MB/sec (max.)      系统可靠性           ECC 技术 内建 ECC 功能           不正常掉电 大于3,000 次           MTBF 大于3,000,000 hours           平均写入 支持     一般技术要求           操作温度    0° C ~ +70° C (标准) -40° C ~ +85° C (工业)           存储温度 -55° C ~ +95° C           湿度 10% ~ 95%不结露           震动 20G(7～2000Hz)           冲击 1,500G maximum     电   源           DC 输入电压 +5V single power supply operation     规   格           外壳 Metal Mechanical Cover           外形尺寸 69.7x99.88x9.3mm(WxLxH)           认证 CE, FCC, RoHS FiD 1.8” SATA 10000       Specifications Capacity 8GB~128GB interface SATA II 3.0G Data Transfer Rate 160MB/sec. ; Write:140MB/sec. Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Storage Temp. -55°C~+95°C Vibration 20G(7~2000Hz) Shock 1500G/0.5ms DC Input Voltage 5V Power Consumption 400mA(max.) Dimension 2.5-69.6 x 99.8 x 9.3mm (WxLxH) / 1.8-54.0 x78.5 x 5mm / SATA Slim:54 x 39 x 4 mm (WxLxH) SMART Function Support Security Function Support   FiD 2.5” SATA10000-RS       Specifications Capacity 2GB~32GB interface SATA II 3.0G Data Transfer Rate Read:100MB/sec. Write:50MB/sec. Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Storage Temp. -55°C~+95°C Vibration 20G(7~2000Hz) Shock 1500G/0.5ms DC Input Voltage 5V Power Consumption 200mA(max.) Dimension 69.6 x 99.8 x 9.3mm (WxLxH) SMART Function Support Security Function Support, AES-128 Encryption FiD 2.5" SATA 10000     D2ST-A28J13C1    2.5" 128GB SATAII 10000 Flash in Disk D2ST-64GJ13C1    2.5" 64GB SATAII 10000 Flash in Disk D2ST-32GJ13C1    2.5" 32GB SATAII 10000 Flash in Disk D2ST-16GJ13C1    2.5" 16GB SATAII 10000 Flash in Disk D2ST-08GJ13C1    2.5" 8GB SATAII 10000 Flash in Disk        W/T FiD 2.5" SATA 10000    D2ST-A28J13W1   W/T 2.5" 128GB SATAII 10000 Flash in Disk D2ST-64GJ13W1   W/T 2.5" 64GB SATAII 10000 Flash in Disk D2ST-32GJ13W1   W/T 2.5" 32GB SATAII 10000 Flash in Disk D2ST-16GJ13W1   W/T 2.5" 16GB SATAII 10000 Flash in Disk D2ST-08GJ13W1   W/T 2.5" 8GB SATAII 10000 Flash in Disk        FID 2.5" SATA10000 RS       D2ST-08GT21C1   2.5" SATA 10000-RS 8GB 4 channels D2ST-04GT21C1   2.5" SATA 10000-RS 4GB 4 channels D2ST-02GT21C1   2.5" SATA 10000-RS 2GB  dual channels D2ST-01GT21C1   2.5" SATA 10000-RS 1GB  dual channels        W/T FID 2.5" SATA10000 RS      D2ST-16GT21W1  W/T 2.5" SATA 10000-RS 16GB 4 channels D2ST-08GT21W1  W/T 2.5" SATA 10000-RS 8GB 4 channels D2ST-04GT21W1  W/T 2.5" SATA 10000-RS 4GB 4 channels D2ST-02GT21W1  W/T 2.5" SATA 10000-RS 2GB  dual channels D2ST-01GT21W1  W/T 2.5" SATA 10000-RS 1GB  dual channels 北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com

产品简介 FiD 2.5” SATA 10000     技术规格           容量 8GB-----128GB           接口 Series ATAII                       尖峰速度 300Mbyte/sec           数据传输速率 读 : 160MB/sec (max.) 写 : 140MB/sec (max.)      系统可靠性           ECC 技术 内建 ECC 功能           不正常掉电 大于3,000 次           MTBF 大于3,000,000 hours           平均写入 支持     一般技术要求           操作温度    0° C ~ +70° C (标准) -40° C ~ +85° C (工业)           存储温度 -55° C ~ +95° C           湿度 10% ~ 95%不结露           震动 20G(7～2000Hz)           冲击 1,500G maximum     电   源           DC 输入电压 +5V single power supply operation     规   格           外壳 Metal Mechanical Cover           外形尺寸 69.7x99.88x9.3mm(WxLxH)           认证 CE, FCC, RoHS FiD 1.8” SATA 10000       Specifications Capacity 8GB~128GB interface SATA II 3.0G Data Transfer Rate 160MB/sec. ; Write:140MB/sec. Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Storage Temp. -55°C~+95°C Vibration 20G(7~2000Hz) Shock 1500G/0.5ms DC Input Voltage 5V Power Consumption 400mA(max.) Dimension 2.5-69.6 x 99.8 x 9.3mm (WxLxH) / 1.8-54.0 x78.5 x 5mm / SATA Slim:54 x 39 x 4 mm (WxLxH) SMART Function Support Security Function Support   FiD 2.5” SATA10000-RS       Specifications Capacity 2GB~32GB interface SATA II 3.0G Data Transfer Rate Read:100MB/sec. Write:50MB/sec. Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Storage Temp. -55°C~+95°C Vibration 20G(7~2000Hz) Shock 1500G/0.5ms DC Input Voltage 5V Power Consumption 200mA(max.) Dimension 69.6 x 99.8 x 9.3mm (WxLxH) SMART Function Support Security Function Support, AES-128 Encryption FiD 2.5" SATA 10000     D2ST-A28J13C1    2.5" 128GB SATAII 10000 Flash in Disk D2ST-64GJ13C1    2.5" 64GB SATAII 10000 Flash in Disk D2ST-32GJ13C1    2.5" 32GB SATAII 10000 Flash in Disk D2ST-16GJ13C1    2.5" 16GB SATAII 10000 Flash in Disk D2ST-08GJ13C1    2.5" 8GB SATAII 10000 Flash in Disk        W/T FiD 2.5" SATA 10000    D2ST-A28J13W1   W/T 2.5" 128GB SATAII 10000 Flash in Disk D2ST-64GJ13W1   W/T 2.5" 64GB SATAII 10000 Flash in Disk D2ST-32GJ13W1   W/T 2.5" 32GB SATAII 10000 Flash in Disk D2ST-16GJ13W1   W/T 2.5" 16GB SATAII 10000 Flash in Disk D2ST-08GJ13W1   W/T 2.5" 8GB SATAII 10000 Flash in Disk        FID 2.5" SATA10000 RS       D2ST-08GT21C1   2.5" SATA 10000-RS 8GB 4 channels D2ST-04GT21C1   2.5" SATA 10000-RS 4GB 4 channels D2ST-02GT21C1   2.5" SATA 10000-RS 2GB  dual channels D2ST-01GT21C1   2.5" SATA 10000-RS 1GB  dual channels        W/T FID 2.5" SATA10000 RS      D2ST-16GT21W1  W/T 2.5" SATA 10000-RS 16GB 4 channels D2ST-08GT21W1  W/T 2.5" SATA 10000-RS 8GB 4 channels D2ST-04GT21W1  W/T 2.5" SATA 10000-RS 4GB 4 channels D2ST-02GT21W1  W/T 2.5" SATA 10000-RS 2GB  dual channels D2ST-01GT21W1  W/T 2.5" SATA 10000-RS 1GB  dual channels 北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com

产品简介 Specifications Item InnoDisk SD card Interface SD 2.0 Speed Class 10 Capacity 1/2/4/8GB Data Transfer Rate  Read:15MB Write:11MB (Max.) Operation Temp. 0°C~70°C -40°C~+85°C Operating Voltage 2.7V to 3.6V Dimension(WxLxH) 24x32x2.1mm    SD Card DS2A-08GI81C1S DS2A-04GI81C1S DS2A-02GI81C1S DS2A-01GI81C1S W/T SD Card DS2A-08GI81W1S DS2A-04GI81W1S DS2A-02GI81W1S DS2A-01GI81W1S 北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com

产品简介 特色 数据写入/保护：快速抹除/保护抹除/写入保护/毁坏 涂层保护膜：腐蚀预防 / MIL-I-46058C硅胶保护涂料 可靠性：高度80,000英尺 宽温：摄氏-40度至85度 温度冲击测试： MIL-STD-810F 503.4 Procedure II 坠落测试： MIL-STD-810F 516.5 Procedure IV，又称Transit Drop specification 冲击测试：1500G Shock / MIL-STD-810F 516.5 specification 40g/11ms/18 shocks (3 shocks for +- X,YZ axis) 震动测试：20G Vibration / MIL-STD-810F 514.5C-1 specification 温度冲击测试：MIL-STD-810-503.4 Procedure II (-40oC to 85oC, 10 cycles) 湿度：5%~95% InnoRobust Ultra SATA Specifications   2.5 SATA High Performance Capacity 16GB~128GB   Performance Sustained Read (MB/s) Read 175MB/sec. Sustained Write (MB/s) Write 90MB/sec. Random Read (IOPS@4KB) 2400 Random Write (IOPS@4KB) 150   Power Consumption Read 740mA(max.) Write 770mA(max.) Idle 460mA(max.)   Environmental Altitude 80,000ft Operating Temperature Standard Grade: 0°C to +70°C ; Industrial Grade: -40°C to +85°C ; Storage Temperature -55°C to +95°C Shock(Operating) 1500G Vibration(Operating) 20G Humidity 5-95%, non-condensing Conformal Coating Optional Write Protect Support DATA Retention 10 years   Dimension Length(mm) 99.88 Width(mm) 69.63 Height(m) 9.3 InnoRobust SATA Specifications   2.5" SATA Capacity 8GB~128GB   Performance base on 8GB Sustained Read (MB/s) Read 155MB/sec. Sustained Write (MB/s) Write 55MB/sec. Random Read (IOPS@4KB) 2300 Random Write (IOPS@4KB) 140   Power Consumption Read 350mA(max.) Write 400mA(max.) Idle 150mA(max.)   Environmental Altitude 80,000ft Operating Temperature Standard Grade: 0°C to +70°C ; Industrial Grade: -40°C to +85°C ; Storage Temperature -55°C to +95°C Shock(Operating) 1500G Vibration(Operating) 20G Humidity 5-95%, non-condensing Conformal Coating Optional Write Protect Support DATA Retention 10 years   Dimension Length(mm) 99.88 Width(mm) 69.63 Height(m) 9.3 InnoRobust PATA Specifications 2.5" PATA Capacity 8GB~128GB   Performance base on 8GB Sustained Read (MB/s) Read 85MB/sec. Sustained Write (MB/s) Write 45MB/sec. Random Read (IOPS@4KB) 2300 Random Write (IOPS@4KB) 140   Power Consumption Read 350mA(max.) Write 400mA(max.) Idle 150mA(max.)   Environmental Altitude 80,000ft Operating Temperature Standard Grade: 0°C to +70°C ; Industrial Grade: -40°C to +85°C ; Storage Temperature -55°C to +95°C Shock(Operating) 1500G Vibration(Operating) 20G Humidity 5-95%, non-condensing Conformal Coating Optional Write Protect Support DATA Retention 10 years   Dimension Length(mm) 100.1 Width(mm) 69.8 Height(m) 9.5 InnoRobust 2.5" SATA SSD Ultra (I-Version FW) D2SH-B56J23C1 D2SR-A28J23C1 D2SR-64GJ23C1 D2SR-32GJ23C1 D2SR-16GJ23C1 W/T InnoRobust 2.5" SATA SSD Ultra (I-Version FW) D2SH-B56J23W1 D2SR-A28J23W1 D2SR-64GJ23W1 D2SR-32GJ23W1 D2SR-16GJ23W1 InnoRobust 2.5" SATA SSD (I Version F/W) D2ST-A28J23C1 D2ST-64GJ23C1 D2ST-32GJ23C1 D2ST-16GJ23C1 D2ST-08GJ23C1 W/T InnoRobust 2.5" SATA SSD (I Version F/W) D2ST-A28J23W1 D2ST-64GJ23W1 D2ST-32GJ23W1 D2ST-16GJ23W1 D2ST-08GJ23W1 InnoRobust 2.5" PATA SSD (I-Version FW) D2D8-A28J23C1 D2D8-64GJ23C1 D2D8-32GJ23C1 D2D8-16GJ23C1 D2D8-08GJ23C1 W/T InnoRobust 2.5" PATA SSD (I-Version FW) D2D8-A28J23W1 D2D8-64GJ23W1 D2D8-32GJ23W1 D2D8-08GJ23W1  北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com

特色 ? 杰出的传输效能 ? 支持SMART功能 ? 支持 Windows 7 TRIM功能 ? 兼容性与扩充性高 ? 智能型区块管理 ? 优化的使用寿命 Specifications  Item  E-class 2.5" SAS SSD    容量 : 64GB~512GB    支持接口: SAS II 6.0G    数据传输速度: Read:190MB/sec. (max.) Write:30MB/sec (max.)    工作环境温度: 0°C~+70°C(Standard)    储存温度  -55°C~+95°C     冲击 : 20G(7~2000Hz)    震動 : 1500G/0.5ms    震动 : 5V    耗电量: 620 mA(max.)    尺寸  69.6x99.8x9.3mm (WxLxH)    SMART 功能支持 : Supported    Security 功能支持 : Supported   北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com

产品简介  Specifications Type Type  DDR2 DIMM DDR2 SO-DIMM  pin pin  240 pin 200 pin  Density Density  256MB~2GB 256MB~2GB  Clock Speed Clock Speed  533MHz/667MHz 533MHz/667MHz  Width Width  64 64  DRAM TOPER DRAM TOPER  40°C~95°C 40°C~95°C  Voltage Voltage  1.8V ±0.1 1.8V ±0.1  Remark Remark  Industrial Grade Industrial Grade    Specifications Type Type  DDR DIMM DDR SO-DIMM  pin pin  184 pin 200 pin  Density Density  128MB~1GB 128MB~1GB  Clock Speed Clock Speed  333MHz/400MHz 333MHz/400MHz  Width Width  64 64  DRAM TOPER DRAM TOPER  40°C~95°C 40°C~95°C  Voltage Voltage  2.5V ±0.2 2.5V ±0.2  Remark Remark  Industrial Grade Industrial Grade    Specifications Type Type  SDRAM DIMM SDRAM SO-DIMM  pin pin  168 pin 144 pin  Density Density  64MB~512MB 64MB~512MB  Clock Speed Clock Speed  100MHz/133MHz 100MHz/133MHz  Width Width  64 64  DRAM TOPER DRAM TOPER  -40°C~95°C -40°C~95°C  Voltage Voltage  3.3V ±0.3 3.3V ±0.3  Remark Remark  Industrial Grade Industrial Grade     北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com

USBDOM 特色 ? 具有弹性的小尺寸设计 ? 容量最高可达8GB(水平) ? 稳定的数据传输效能 ? 符合RoHS规范 Specifications Item USB EDC(V) 容量 512MB~4GB 支持接口 Hi-Speed USB2.0 数据传输速度 Read : 26MB/sec. Write : 12MB/sec. 工作环境温度 0℃~+70℃ 储存温度 -55℃~+95℃ 电源 +5V single power supply operation 电源模式 Auto stand-by mode 耗电量 120mA (max.) 尺寸 15.2 x 34.1 x 6.4 mm(WxLxH) USB-EDC, Vertical DEUX-04GU52C1S DEUX-02GU52C1S DEUX-01GU52C1S DEUX-512U52C1S DEUX-256U51C1S DEUX-128U51C1S USB-EDC, Horizontal, Pin Pitch 2.00mm DEUP-08GU52C1 DEUP-04GU52C1 DEUP-02GU52C1 DEUP-01GU52C1 DEUP-512U52C1 DEUP-256U51C1 DEUP-128U51C1     USB-EDC, Horizontal, Pin Pitch 2.54mm DEUF-08GU52C1 DEUF-04GU52C1 DEUF-02GU52C1 DEUF-01GU52C1 DEUF-512U52C1 DEUF-256U51C1 DEUF-128U51C1 北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com

SATADOM i-100 Specifications Capacity 2GB~ 16GB(Ultra up to 32GB) interface SATA II 3.0G Data Transfer Rate Read:100MB/sec.(max.) Write: 50MB/sec.(max.) Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Storage Temp. -55°C~+95°C Vibration 20G(7~2000Hz) Shock 1500G/0.5ms DC Input Voltage 5V Power Consumption Auto stand-by mode Power Consumption 170mA(max.) Dimension 25mm x 39.4mm x 6.5mm (WxLxH) 32GB-25mm x 39.4mm x 9.5mm (WxLxH) SATADOM i-100 Vertical DESIU-32GT21C1D DESIU-16GT21C1D DESIU-08GT21C1D DESIU-04GT21C1D DESIU-02GT21C1D DESIU-02GT21C1S W/T SATADOM i-100 Vertical DESIU-32GT21W1D DESIU-16GT21W1D DESIU-08GT21W1D DESIU-04GT21W1D DESIU-02GT21W1D DESIU-02GT21W1S SATADOM i-100 Vertical W/FUSE DESIU-32GT21C1DF DESIU-16GT21C1DF DESIU-08GT21C1DF DESIU-04GT21C1DF DESIU-02GT21C1DF DESIU-02GT21C1SF W/T SATADOM i-100 Vertical DESIU-32GT21W1DF DESIU-16GT21W1DF DESIU-08GT21W1DF DESIU-04GT21W1DF DESIU-02GT21W1DF DESIU-02GT21W1SF SATADOM i-100 Horizontal DESIB-32GT21C1D DESIB-16GT21C1D DESIB-08GT21C1D DESIB-04GT21C1D DESIB-02GT21C1D DESIB-02GT21C1S W/T SATADOM i-100 Horizontal DESIB-32GT21W1D DESIB-16GT21W1D DESIB-08GT21W1D DESIB-04GT21W1D DESIB-02GT21W1D DESIB-02GT21W1S SATADOM i-100 Horizontal W/ FUSE DESIB-32GT21C1DF DESIB-16GT21C1DF DESIB-08GT21C1DF DESIB-04GT21C1DF DESIB-02GT21C1DF DESIB-02GT21C1SF W/T SATADOM i-100 Horizontal W/ FUSE DESIB-32GT21W1DF DESIB-16GT21W1DF DESIB-08GT21W1DF DESIB-04GT21W1DF DESIB-02GT21W1DF DESIB-02GT21W1SF 北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com SATADOM i-100  Specifications Capacity 2GB~ 16GB(Ultra up to 32GB)  interface SATA II 3.0G  Data Transfer Rate Read:100MB/sec.(max.) Write: 50MB/sec.(max.)  Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial)  Storage Temp. -55°C~+95°C  Vibration 20G(7~2000Hz)  Shock 1500G/0.5ms  DC Input Voltage 5V  Power Consumption Auto stand-by mode  Power Consumption 170mA(max.)  Dimension 25mm x 39.4mm x 6.5mm (WxLxH) 32GB-25mm x 39.4mm x 9.5mm (WxLxH) 北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com

产品简介 SATADOM Specifications Capacity 128MB~8GB interface SATA I 1.5G Data Transfer Rate Read : 24MB/sec Write: 14MB/sec. Operation Temp. 0°C~+70°C(Standard) ; -40°C~+85°C(Industrial) Storage Temp. -55°C~+95°C Vibration 5G(7~2000Hz) Shock 50G/10ms DC Input Voltage 5V Power Consumption Auto stand-by mode Power Consumption 180mA (max.) Dimension Vertical H-P: 20.8mm x 32.8mm x 8.0mm (WxLxH) R type: 20.5mm x 32.8mm x 8.0mm (WxLxH) L type: 20.5mm x 32.8mm x 8.0mm (WxLxH) L-P(Vertical): 32.8mm x 29.6mm x 8.0mm (WxLxH) Horizontal H-P: 18.0mm x 30.3mm x 11.4mm (WxLxH) L-P(Horizontal):30mm x 20.3mm x 11.4mm (WxLxH) SATADOM, Vertical DES9-08GT11C2S DES9-04GT11C2S DES9-02GT11C2S DES9-01GT11C2S DES9-512T11C2S DES9-256T11C2S DES9-128T11C2S W/T SATADOM, Vertical DES9-08GT11W2S DES9-04GT11W2S DES9-02GT11W2S DES9-01GT11W2S DES9-512T11W2S DES9-256T11W2S DES9-128T11W2S SATADOM, Vertical W/FUSE DES9-08GT11C2SF DES9-04GT11C2SF DES9-02GT11C2SF DES9-01GT11C2SF DES9-512T11C2SF DES9-256T11C2SF DES9-128T11C2SF W/T SATADOM, Vertical W/FUSE DES9-08GT11W2SF DES9-04GT11W2SF DES9-02GT11W2SF DES9-01GT11W2SF DES9-512T11W2SF DES9-256T11W2SF DES9-128T11W2SF SATADOM, Horizontal B type DES9B-08GT11C2S DES9B-04GT11C2S DES9B-02GT11C2S DES9B-01GT11C2S DES9B-512T11C2S DES9B-256T11C2S DES9B-128T11C2S W/T SATADOM, Horizontal B Type DES9B-08GT11W2S DES9B-04GT11W2S DES9B-02GT11W2S DES9B-01GT11W2S DES9B-512T11W2S DES9B-256T11W2S DES9B-128T11W2S SATADOM, Horizontal pin B type, 7 w/FUSE DES9B-08GT11C2SF DES9B-04GT11C2SF DES9B-02GT11C2SF DES9B-01GT11C2SF DES9B-512T11C2SF DES9B-256T11C2SF DES9B-128T11C2SF W/T SATADOM, Horizontal pin B type, 7 w/FUSE DES9B-08GT11W2SF DES9B-04GT11W2SF DES9B-02GT11W2SF DES9B-01GT11W2SF DES9B-512T11W2SF DES9B-256T11W2SF DES9B-128T11W2SF 北京伟天达科技，主要销售：DOM电子盘、宽温电子盘、固态硬盘、宽温CF卡、宽温内存条 电话：010-13146512271 QQ：546288802 MSN：m-l-w168@hotmail.com http://miaoliwei168.ebdoor.com
